Jindal SS 304 Pipe Weight Calculator & Chart (Latest 2026)
Jindal SS 304 pipes are among the most widely used stainless steel pipes in India due to their high corrosion resistance, durability, and hygienic properties. For engineers and contractors, understanding the Jindal stainless steel pipe weight per meter is essential for accurate planning and cost estimation.
This guide includes:
- Jindal SS 304 pipe weight calculator
- Jindal pipe weight chart (latest 2026)
- SS pipe Jindal weight list
- Formula + tables + examples
What is Jindal SS 304 Pipe?
Jindal SS 304 pipes are made from austenitic stainless steel (304 grade) containing chromium and nickel, offering:
- Excellent corrosion resistance
- High strength
- Long service life
- Suitable for pharma, dairy, and industrial use
These pipes are available in multiple sizes, schedules, and thicknesses, which directly affect their weight. ()
Jindal SS 304 Pipe Weight Formula
The standard formula used in Jindal pipe weight calculator is:
Weight (kg/m) = (OD − WT) × WT × 0.0248
Where:
- OD = Outer Diameter (mm)
- WT = Wall Thickness (mm)
- 0.0248 = Constant for SS 304 density ()
Example Calculation
- OD = 50 mm
- WT = 2 mm
Weight = (50 − 2) × 2 × 0.0248
Weight = 48 × 2 × 0.0248 = 2.38 kg/m
Jindal SS 304 Pipe Weight Chart (Kg/mtr)
Common Sizes (Metric Chart)
OD (mm) | WT (mm) | Weight (kg/m) |
21.3 | 2.11 | 1.02 |
26.9 | 2.11 | 1.29 |
33.7 | 2.77 | 2.12 |
42.4 | 2.77 | 2.69 |
48.3 | 3.68 | 4.05 |
60.3 | 3.91 | 5.44 |
76.1 | 3.91 | 6.93 |
88.9 | 5.49 | 11.49 |
114.3 | 6.02 | 16.07 |
👉 These values are based on standard Jindal stainless steel pipe weight charts. ()
Jindal Pipe Weight Chart (Schedule-Based)
Schedule 10 / 40 / 80 Comparison
Size (Inch) | Sch 10 (kg/m) | Sch 40 (kg/m) | Sch 80 (kg/m) |
1/2″ | 0.81 | 1.15 | 1.48 |
1″ | 1.40 | 1.68 | 2.17 |
2″ | 2.64 | 3.91 | 5.54 |
3″ | 4.89 | 9.42 | 12.60 |
4″ | 7.39 | 14.14 | 19.92 |
👉 Higher schedule = higher thickness and weight
SS Pipe Jindal Weight List (Large Sizes)
OD (mm) | Thickness (mm) | Weight (kg/m) |
168.3 | 7.11 | 28.26 |
219.1 | 8.18 | 43.60 |
273.1 | 9.27 | 61.41 |
323.9 | 10.31 | 82.77 |
355.6 | 12.70 | 109.04 |
👉 Large diameter pipes are used in industrial pipelines and process plants. ()
Pipe Weight Trend Chart
Thickness vs Weight
Thickness | Weight Impact |
Thin (1–2 mm) | Light |
Medium (3–5 mm) | Moderate |
Thick (6+ mm) | Heavy |
👉 Insight: Weight increases non-linearly with thickness.
Jindal SS 304 Pipe Weight Calculator (How to Use)
Steps:
- Enter Outer Diameter (OD)
- Enter Wall Thickness (WT)
- Apply formula
- Get weight in kg/m
You can create:
- Excel calculator
- Online web tool
- ERP-integrated system
Why Jindal Pipe Weight is Important
Knowing Jindal stainless steel pipe weight helps in:
- Project cost estimation
- Load and structural design
- Transport planning
- Material procurement
Key Features of Jindal SS 304 Pipes
- Corrosion-resistant
- Long-lasting
- Hygienic (ideal for pharma & dairy)
- Available in multiple schedules
Pro Tips
- Always use correct OD & schedule
- Refer to official Jindal charts for accuracy
- Use Schedule 10 for lightweight applications
- Use Schedule 80 for high-pressure systems
Conclusion
The Jindal SS 304 pipe weight calculator and chart (2026) helps engineers and buyers quickly determine accurate pipe weight. By using the correct formula, schedule charts, and weight tables, you can ensure better planning, cost control, and system efficiency.
